In 17th May Jinan Liaoyuan Machine Co., Ltd, Shandong Glory dispatched one set of CNC steel plate punching drilling machine CPD103 to Russia
2022-02-11

In 17th May Jinan Liaoyuan Machine Co., Ltd, Shandong Glory dispatched one set of CNC steel plate punching drilling machine CPD103 to Russia



Features:

1. C shape framework features great rigidity and spacious working area.

2. There are four working stations, Stations can change automatically. The clamp system is suitable for workpiece with different thicknesses. There is stop locater at zero position. Workpiece is supported by working table with rolling balls.

3.X and Y axis are driven by servo motor and ball screw. The punching position is controlled by bi-axis CNC controlling system. The Processing data can be input into the controlling system and the processing can be done automatically .And the data inputted can be used for next times.


Advantage:

1.Integrated machine with mechanical, electrical, and hydraulic system. PLC control and servo motor drive.

2.Modular assembling for main functional parts, easy maintenance, self-diagnostic function.

3.Punching, Marking and drilling operations on one plate with less labor force and steady precision.

4.For programming, either input punching diameter, position and quantity of workpiece or directly share the date source of design department by the local network


The dispatching photos:
